Access Channel
36 channels
Network Bandwidth
320 Mbps incoming and 320 Mbps outgoing
Playback Decoding
Text Text Text
Video Compression
4-channel 8 MP@15 fps; 4-channel 6 MP@25 fps; 4-channel 5 MP@30 fps; 5-channel 4 MP@30 fps; 10-channel 1080p@30 fps
Back-up File Format
MP4
Wired Network
1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Compatible APP
Eimou Home APP (IOS&Android)
Third Party Agreement
Onvif
Video Output
1*HDMI：4K (3840 × 2160）, 2K (2560 × 1440）, 1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720 1*VGA：1920 × 1080, 1280 × 1024, 1280 × 720
Audio Input
1*Microphone(Built-in)
Audio Output
1*Speaker(Built-in)
USB Interface
2*USB
Reset Button
YES
Network Interface
1 RJ–45 port (10/100 Mbps)
IPC Connection
Automatically connect to EIMOU cameras
Smart Detection
Motion / Person / Vehicle
Remote Upgrade
Yes
Sound Channel
Two-Way Audio
Hard Drive Capacity
2 SATA port, up to 16 TB
Backup Media
USB Flash Drive
Power Supply
12V 2A
Working Temperature
-10℃~+45℃
Working Humidity
Less Than 95%RH
